FSE 776 radiobus

Maximum performance for crane and machine control. With 100 control functions, 10 analog commands, and the versatile modular radiobus® system, this receiver truly leaves nothing to be desired.

Output elements

• Up to 100 relays
• Proportional: 0 – 10 V or 0 – 20 / 4 – 20 mA
• Diverse analog and serial interfaces, for example CANopen, Profibus-DP, RS232/485, Profinet, SAE J1939, UART, IQAN and DeviceNet
• radiobus^® technology = individual configuration via modular plugin cards – number of card slots: 13

Control functions

• Output of 100 control functions (on / off)
• Up to 10 analog commands (maximum number of additional on / off commands depending on the configuration)
• For serial interfaces: depending on the protocol definition

Indication

• LEDs for the indication of operating status
